TECNA 9203 Hose Balancer 3–5 kg, 900 mm Stroke

TECNA 9203 hose balancer is an industrial pneumatic tool balancer with polyurethane hose, designed for tools weighing 3–5 kg. It provides a 900 mm stroke and supports the pneumatic tool directly by the hose, helping minimise the overall dimensions of the workstation.

The balancer features a rugged cast aluminium body and adjustable capacity. Properly sized springs are designed to provide smooth operation and long service life.

An adjustable stroke limiting device allows the tool's movement range to be set according to the workstation. An auxiliary safety suspension provides an additional safety point for installation.

The integrated polyurethane hose serves as both the tool support and pneumatic air connection. Maximum operating pressure is 8 bar, while maximum operating temperature is 50°C.

The TECNA 9203 has a net weight of 1.35 kg. Package dimensions are 225 × 160 × 110 mm.

Technical Specifications

• Brand: TECNA
• Model: 9203
• Type: pneumatic hose balancer
• Capacity: 3–5 kg
• Stroke: 900 mm
• Hose material: polyurethane
• Body: cast aluminium
• Adjustable capacity: yes
• Stroke limiting device: adjustable
• Auxiliary safety suspension: yes
• Maximum operating pressure: 8 bar
• Maximum operating temperature: 50°C
• Application environment: industrial
• Net weight: 1.35 kg
• Gross weight: 1.60 kg
• Package dimensions: 225 × 160 × 110 mm

Key Features

• Adjustable 3–5 kg capacity
• 900 mm stroke
• Integrated polyurethane air hose
• Rugged cast aluminium body
• Adjustable stroke limiting device
• Auxiliary safety suspension
• Tool is supported directly by the hose
• Maximum operating pressure of 8 bar

Applications & Usage

The TECNA 9203 hose balancer is designed to support and balance pneumatic tools weighing 3–5 kg in industrial workstations.

The polyurethane hose combines tool suspension and compressed-air supply in one system. It is suitable for production and assembly stations where pneumatic tools are used repeatedly and a 900 mm working stroke is required.

Advantages

• Supports pneumatic tools weighing 3–5 kg
• Hose combines tool suspension and compressed-air connection
• Compact design minimises workstation space requirements
• Capacity can be adjusted to suit the tool weight
• Adjustable stroke limiter controls the working range
• Cast aluminium body is designed for industrial use
• Auxiliary safety suspension provides an additional installation safety point

Applications / Industries

• Industrial manufacturing
• Assembly lines
• Production assembly
• Pneumatic tool workstations
• Production stations
• Professional workshops
